+12V: 100 A
, +3.3V: 25 A
, +5V: 22 A
, +5VSB: 3 A
, -12V: 0.3 A
, 20+4-pin Main Connector: 1
, 4/8-pin +12V Power Connector: 2
, 4-pin Floppy Drive Connector: 2
, 4-pin Peripheral Power Connector: 6
, 6/8-pin PCI Express Connector: 8
, Box Weight Brutto (kg): 12 kg
, Certifications: 80 PLUS Platinum
, Circuit Protection: Over Voltage Undervoltage Over Temperature Over Current Short Curcuit Protection Over Power
, Depth (mm): 140 mm
, EAN Code: 4710007226582
, Efficiency: 92%
, External Color: Black
, Fan Diameter: 120 mm
, Fans Installed Quantity: 1
, Height (mm): 86 mm
, Included Accessories: Quick Start Guide
, Input Frequency: 47/63 Hz
, Input Power Connectors Quantity: 1
, Input Voltage: AC 90-264 V
, Material: Metal
, Maximum Fans Supported Quantity: 1
, Maximum Operating Ambient Temperature: 40 °C
, Maximum Output Power: 1200 W
, Mean Time Between Failures: 100000 hr
, Minimum Operating Ambient Temperature: 0 °C
, Modular Power Supply: Yes
, Nominal Weight: 2 kg
, Output Voltage: DC 3.3/5/±12 V
, Pack Weight Brutto (kg): 2 kg
, Pack Weight Netto (kg): 1.98 kg
, Package Type: Retail
, Packs in Box: 6
, Pieces in pack: 1
, Power Adapter and Power Supply Features: Active PFCLow noise
, Power Device Location: Plug-in-module
, Power Device Type: Power Supply
, Retail Packaging Net Weight Carton: 0.01 kg
, Retail Packaging Net Weight Plastic: 0.01 kg
, S-ATA Connector: 8
, Warranty Products Returnable: Yes
, Warranty Term (month): 60 month(s)
, Warranty validation Criteria: Serial Number
, Width (mm): 150 mm
